4-channel Universal Lighting Control Module supports dimming of
both forward and reverse phase
Description
The DIN-DM4 is a 4-channel universal lighting control module
designed to support dimming of both forward and reverse phase type
loads.
A single model supports 4-Way 1.5A Dimming, Each channel Can
Control 330W Load Independently , 2channel Or More channel
Combining Power Output At Optional, Maximum 6A (1300W) Combining
Output.
Enclosure
Light gray polycarbonate housing with polycarbonate label overlay,
UL94 V-0 rated, 35mm DIN EN 60715 rail mount, DIN 43880 form
factor for enclosures with 45mm front panel cutout, occupies 8 DIN
module spaces (143mm)
Load Types | Incandescent loads or LEDLamps |
Line Power | 120 to 240 Volts AC, 50/60 Hz |
| size | 143mm(Length)*98mm(Width)*68mm*(Height) |
weight | 450 g |
1.Emergency Manual Switch Helps You Test Easily. Operating State
Indicator Lamps Help You Check Operating State Clearly.
2.With 1-Way Bus Input Port, 1 Way Bus Output Port And 1 Way Forced
Switch Port.
3.DC-NET ID Number Digital Display Is On The Front Panel Of The
Device . The ID Number Can Be Set Via The Panel Keys.
4.DC-NET Bus Communication, Different Controlling Ways Include Pc
Tablet Mobile Phone Control Panel Sensor,etc.
5.It is compatible with RS-485 Bus Communication, Supports Multiple
Controlling Protocols Such as DMX, MODBUS RTU, MODBUS ASCII, And
Third-Party Protocols, Supporting AMX, CRESTRON, C4 And All
Third-Party Control Systems
Different packing at optional:
1. Retailing Packing:
Neutral Carton Package
2. Bulking Packing:
Carton Package-Can save packing cost
Anti-static bag--Can protect electronic components from potential
electrostatic hazards
3. Customized Packing
Can design and pack according to your requirement,such as colorful
box,blister packing,sealed packing with your company information,
bar code,ect. ( Discuss extral)
FAQ:
1. What is intelligent lighting control system?
A lighting control system is an intelligent network based lighting
control solution that incorporates communication between various
system inputs and outputs related to lighting control with the use
of one or more central computing devices. Lighting control systems
are widely used on both indoor and outdoor lighting of commercial,
industrial, and residential spaces.
2. What is the advantage compare with the traditional lighting
control?
Improve energy efficiency
Reduce maintenance cost
Easy operation and more convenient
3. What Okystar can supply for you?
Okystar can offer a whole solution of lighting control system for
you, economic and customization, with industrial-grade design,
product architecture in line with international electrical
standards, using high-quality components, products are stable and
reliable.
